Multi-resistant ceramic lined composite pipe

on

 Multi-resistant ceramic lined composite pipe can be widely used in electricity, coal, steel , petroleum, metallurgy , mining, building materials, chemicals and energy industries, transport ash, slag , coal , ore, cement , sand and other granular materials , grinding cut ideal medium wear pipeline , not only can greatly reduce the maintenance costs of materials , and can solve many of these industries major technical problems.




Features of Multi-resistant ceramic lined composite pipe:

Alumina is a cost effective and widely used material in the family of engineered ceramics. Alumina ceramics have been developed and optimized for maximum wear resistance and corrosion resistance.

A high density, diamond like hardness,fine grain structure and superior mechanical strength are the unique properties that make it the material of choice for a wide range of demanding applications.Ceramic has uses similar to Cast Basalt but it has greater resistance to wear in high velocity applications and impact resistance in extreme dynamic systems .

Main Properties of Ceramic

Item

Index

Content of Alumina

≥95%

Density

≥3.5 g/cm3

Rockwell Hardness

≥80 HRA

Impact Strength

≥850 Mpa

Bending Strength

 ≥290MPa

Breaking Temper

≥4.8MPa·m1/2

Coefficient of Linear Thermal Expansion

20W/m.K

Due to the above properties of Alumina Ceramic,Ceramic Lined Pipe Elbows have the following superiorities.
